321H Stainless Steel Hot Rolled Sheets, 321 Stainless Steel Sheet, SS 321 Sheets Stockist, SS 321H Sheets, UNS S32100 Sheet, 321 SS Sheet, 1.4878 Sheets, Stainless Steel 321 Sheets, ASTM A240 TP321 Stainless Steel Sheets, Stainless Steel 321H Sheets Supplier in Mumbai, India.
Palgotta Steel Pvt Ltd offers 321H/321 stainless steel sheet, versatile and highly corrosion-resistant stainless steel with superior strength, excellent oxidation resistance, and low maintenance requirements. It is ideal for various applications, such as pressure vessels, marine environments, chemical processing, and oil & gas industries. 321 Stainless Steel Sheet is non-magnetic in the annealed condition but slightly magnetic in the cold-worked state. It is highly resistant to intergranular corrosion, making it suitable for components exposed to various temperatures. Also, it performs well with nitric acid and other organic and inorganic compounds.
SS 321H CR Sheets, Stainless Steel 321 Sheet Manufacturers, SS 321 Shim Sheets, 321 Stainless Steel Sheet Suppliers, Jindal Stainless Steel Sheet 321 Price List, ASME SA240 TP321 SS Sheet, Stainless Steel 321H Perforated Sheets, Stainless Steel 321H Sheets Stockist in India.
What is 321H/321 stainless steel sheet?
321H/321 stainless steel sheet is a type of austenitic stainless steel that contains titanium as a stabilizing element. It has excellent resistance to intergranular corrosion and can withstand high temperatures up to 800-1500°F. 321H stainless steel has a higher carbon content than 321 stainless steel, making it more suitable for high-temperature applications requiring greater strength and creep resistance. Due to their excellent resistance to oxidation, high strength, and low maintenance requirements, these sheets are widely used in various industries, such as chemical processing, oil and gas, and aerospace.
What are the features of 321H/321 stainless steel sheets?
The 321H/321 SS Sheet features include corrosion resistance, high-temperature resistance, strength, versatility, and low maintenance requirements. They are highly resistant to intergranular corrosion, stress corrosion cracking, and pitting. Adding titanium and carbon gives these sheets superior strength and resistance to creep, making them ideal for high-temperature applications. They are also highly formable, weldable, and machinable, making them suitable for various industrial applications.
What are the advantages of 321H/321 stainless steel sheets?
The advantages of the 321H/321 SS Sheet include excellent resistance to intergranular corrosion, stress corrosion cracking, and pitting, high-temperature resistance, superior strength and resistance to creep, versatility, and low maintenance requirements.
What are the applications of 321H/321 stainless steel sheets?
321H/321 stainless steel sheet is widely used in various applications, including chemical processing, oil and gas, aerospace, and marine environments. They are suitable for high-temperature applications and components exposed to corrosive environments. These sheets are used for pressure vessels, heat exchangers, expansion bellows, and exhaust systems. They are used in the manufacturing of food and pharmaceutical industries and in structural components for the construction industry.
Stainless Steel 321 Sheet Grades and Specification
- Sheet Standards: ASTM A240 / ASME SA240
- Sheet Dimensions: ASTM, ASME, and API
- Material: Stainless Steel
- Sheets Width: 160 – 1.500,00 mm
- Sheets Thickness: 0.2 – 6.0 mm
- Sheets Length: 100 to 6.000,00 mm
- Sheets Tolerance: acc. EN ISO 9445:2006 other on request
- Surface finishes: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, perforated, embossed, hairline, sand blast, Brush, etching, Hot rolled Sheet (HR), Cold rolled Sheet (CR), SATIN (Met with Plastic Coated) etc
- Hardness: Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
- Types: Sheets, Perforated Sheet
Equivalent Material of Stainless Steel 321 Sheets
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| SS 321H | 1.4878 | S32109 | SUS 321H | X12CrNiTi18-9 |
Specialized in Stainless Steel 321 Sheets
- AISI 321H Sheets
- Stainless Steel 321H Sheets Stockholder
- SS 321 2D Finish Sheets Supplier
- 321 Stainless Steel Hot Rolled Sheets
- Stainless Steel 321H Perforated Sheets
- Stainless Steel 321H Shim Sheets
- 321H SS #4 Polish Finish Sheets
- SS 321 2B Finish Sheets in Mumbai
- Stainless Steel 321 BA Finish Sheet in India
- Austenitic Stainless Steel 321H Sheets
- Stainless Steel 321 Industrial Sheets
- Stainless Steel 321 Sheets Stocks
- 321H Stainless Steel Sheets Manufacturer
- SS 321 Sheets at Best Price List In India
- SUS 321H Sheets
- ASTM A240 TP321H SS Sheets
- Stainless Steel 321 Cold Rolled Sheets
- Cut To Size Stainless Steel 321H Sheet
- ASME SA240 TP321 Stainless Steel Sheets
- Stainless Steel 321 Sheets Exporters
- 321 Stainless Steel Sheets Stockist In Mumbai
- Stainless Steel 1.4541 Sheets
- Stainless Steel UNS S32109 Sheets
- Stainless Steel 321H Sheets Supplier in India
- Stainless 321 Sheets Wholesale in Mumbai
- #8 Mirror Polish Finish Stainless Steel 321 Sheets
- Stainless Steel 321H Sheets Supplier in India
- 321 SS Both Side Polished Sheet
Chemical Properties Of 321 Stainless Steel Sheet
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| SS 321H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
SS 321 Sheets Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
ASME SA240 Stainless Steel 321 Sheet Sizes
| SS 321H Sheet Weight per Unit Area | Estimated Weight per Sheet |
|---|---|
| 0.630 lbs/ft²3.07566 kg/m² | 15.12 lbs6.84936 kg |
| 0.630 lbs/ft²3.07566 kg/m² | 18.90 lbs8.5617 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 18.15 lbs8.22195 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 22.68 lbs10.27404 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 24.19 lbs10.95807 kg |
| 0.756 lbs/ft²3.690792 kg/m² | 30.24 lbs13.69872 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 20.16 lbs9.13248 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 25.20 lbs11.4156 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 24.19 lbs10.95807 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 30.24 lbs13.69872 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 36.29 lbs16.43937 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 32.26 lbs14.61378 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 40.32 lbs18.26496 kg |
| 1.008 lbs/ft²4.921056 kg/m² | 48.39 lbs21.92067 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 25.20 lbs11.4156 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 31.50 lbs14.2695 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 30.24 lbs13.69872 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 37.80 lbs17.1234 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 45.37 lbs20.55261 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 40.32 lbs18.26496 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 50.41 lbs22.83573 kg |
| 1.260 lbs/ft²6.15132 kg/m² | 60.49 lbs27.40197 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 30.24 lbs13.69872 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 37.80 lbs17.1234 kg |
| 1.512 lbs/ft²7.381584 kg/m² | 36.29 lbs16.43937 kg |
321H Stainless Steel Sheet Thickness & Weight
| Thickness | Thickness | Size Chart | SS 321 Sheet Unit weight | SS 321H Sheet Approx Weight | ||
|---|---|---|---|---|---|---|
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
Stainless Steel 321 Sheet Dimensions
| Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | 1524 |
| 2H – Work hardened | 0.4–6.35 | 1524 |
| Polished, brushed | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | 60 |
| Polished (not brushed) | 11–24 | 60 |
Polished and Plain 321 Stainless Steel Sheet
huge stock of polished ss 321 sheets, finishes include Natural, Bright, Brushed, Dull Polished, Mirror and Embossed Rigidised
| PRODUCT | FINISH | THICKNESS MM | MAX SHEET SIZE MM |
|---|---|---|---|
| Grade 321 | Plain 2B | 0.9 | 2000 x 1000 |
| Bright | 0.9 | 2000 x 1000 | |
| Brushed Finish | 0.9, 1.2 | 2000 x 1000, 2500 x 1250 | |
| Rimex Super Mirror | 0.8, 1.2 | 2400 x 1200, 2500 x 1250 | |
| Embossed | 0.8, 1.0 | 2500 x 1250 |
Perforated Stainless Steel Sheet 321
We now offer circle cutting in Stainless Steel Grade 321H perforated sheets up to 1000mm diameter.
| Hole Dia mm | Hole Centres mm | O/A | Finish | Tck mm | Full Sheet Size mm |
|---|---|---|---|---|---|
| 0.75 | 1.5 | 23% | 2B | 0.6 | 2000 x 1000 |
| 1 | 2 | 23% | 2B | 1.0 | 2000 x 1000 |
| 1.5 | 2.6 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 2 | 3.5 | 30% | 2B | 1.0 | 2000 x 1000 |
| 3 | 5 | 33% | 2B | 1.0 | 2000 x 1000 |
| 4 | 5.6 | 46% | 2B | 1.0 | 2000 x 1000 |
| 5 | 8 | 35% | 2B | 1.0 | 2000 x 1000 |
| 6 | 8 | 51% | 2B | 1.0 | 2000 x 1000 |
| 8 | 10 | 58% | 2B | 1,0 | 2000 x 1000 |
321 Stainless Steel Sheet Price List
- a240 tp321h stainless steel sheet – no.8 mirror polish
us $100-1200 / ton - mirror / polish / brush finished 321 stainless steel sheet
us $1100-2000 / ton - cold rolled / hot rolled 321 stainless steel sheet
us $1000-1500 / ton - cheap price no.1 2b surface stainless steel sheet 321
us $1200-1980 / ton - 321h 2b surface stainless steel metal sheet
us $1500-3000 / ton - grade 321 hot rolled and cold rolled steel sheet
us $1090-2240 / ton - no.1 2b sheet and 2b finish 321 stainless steel Sheet price
us $11-50& nbsp;/ piece - the most popular stainless steel sheet 321h / sus 321 2b manufacturer
us $230-1980 / ton - top quality 321h stainless steel sheet with factory price
us $1000-2090 / ton - 321 2b finish stainless steel sheet price
us $1000-2300 / ton
Stainless Steel 321 Sheet Latest Price | Stainless Steel 321H Sheet Manufacturers | Stainless Steel 321H Sheet Suppliers | Stainless Steel 321 Sheet | Stainless Steel 321 Sheet Stockists | Stainless Steel 321H Sheet Exporters | Supplier of Stainless Steel 321H Sheet
Stainless Steel 321 Sheet Value Added Services / Processing
- Cladding
- Heat Treatment
- Annealed
- Pickling, Polish
- Rolling
- Cutting
- Bending
- Forging
- Minor Fabrication etc.
- Drilling
- Milling
- Punching
- Forming
- Hot Forming
- Welding
- Shearing
- Grinding
- Testing
Export Destinations For SS 321H Sheets
Puerto Rico, Hong Kong, Japan, China, Peru, Singapore, Yemen, Nepal, Bangladesh, Thailand, Oman, Saudi Arabia, Israel, Malaysia, South Korea, Ecuador, Qatar, Gambia, United Kingdom, Portugal, Denmark, Colombia, Gabon, Mexico, Nigeria, Germany, Jordan, Indonesia, Iraq, Afghanistan, South Africa, Azerbaijan, Ghana, United Arab Emirates, Zimbabwe, Mongolia, Russia, India, Lithuania, Estonia, Costa Rica, Chile, Serbia, New Zealand, Bolivia, Algeria, Tibet, Venezuela, Italy, Belarus, Spain, Canada, Australia, Tunisia, Philippines, Kuwait, Angola, Trinidad & Tobago, Lebanon, Norway, Slovakia, Bulgaria, Vietnam, Namibia, Hungary, France, Croatia, Romania, Ireland, Czech Republic, Netherlands, Ukraine, Morocco, Bhutan, Turkey, Argentina, Lahore, Brazil, Algiera, Egypt, Kazakhstan, Sri Lanka, Macau, Taiwan, Bahrain, Iran, Finland, Austria, United States, Libya, Switzerland, columbia, Greece, Pakistan, Kenya, Sweden, Belgium, Poland.
Domestic Supply For Stainless Steel 321 Sheets
Visakhapatnam, Hyderabad, Pune, Thane, Kolkata, Ranchi, Bengaluru, Haryana, Bhopal, Ahmedabad, Nagpur, Thiruvananthapuram, Navi Mumbai, Rajkot, mumbai, Indore, Nashik, Jamshedpur, Secunderabad, Noida, Jaipur, Faridabad, Gurgaon, Pimpri-Chinchwad, Chandigarh, Surat, New Delhi, Ernakulam, Howrah, Ludhiana, Chennai, Kanpur.
